DTS XR9 Spot User Manual

-
ARC 1200
XR 9 SPOT
23
DMX CHANNEL 12
Parameter: GOBO 2
DMX range
Value
Mid point
DMX value
Move
range
(degrees)
Mode Option Function
0-15 Open
16-31 Gobo 1
32-47 Gobo 2
48-63 Gobo 3
64-79 Gobo 4
80-95 Gobo 5
96-111 Gobo 6
112-127 Gobo 7
128-143
144-159
160-175
176-191
192-199 Speed rotation 1 min
200-207 Speed rotation 2
208-215 Speed rotation 3
216-223 Speed rotation 4
224-231 Speed rotation 5
232-239 Speed rotation 6
240-247 Speed rotation 7
248-255 Speed rotation 8 max.
Gobo 8
Gobo 9
Gobo 10
Gobo 11
DMX CHANNEL 13
Parameter: IRIS
DMX range
Value
Mid point
DMX value
Move
range
(degrees)
Mode Option Function
0-9
Open
10-160
Linear Iris from Open to Closed
Iris pulse at different speeds from Max to Min
161-171
172-199
200-227
228-255
Iris pulse with flash closing from Min to Max
Iris pulse with flash openig from Min to Max
Closed
DMX CHANNEL 14
Parameter: PRISM-PRISM ROTATION
DMX range
Value
Mid point
DMX value
Move
range
(degrees)
Mode Option Function
0-63
No effect
64-127
Prism inserted
Right Rotation
128-191
192-255
Left Rotation
