Ducane 4AC13 - Cooling Performance with Air Handlers and Furnaces

4AC13 Split System Air Conditioner
13
Outdoor
Model
Indoor Model
SEER EER
Rated
ARI
Capacity
1
Rated
Sensible
Capacity
CFM
Refrigerant
Connection
Refrigerant
Line Size
Indoor Metering
Device
Piston or Field
Installed TXV
Factory
Installed
TXV
Outdoor Indoor
Suction
Liquid
Req'd
Indoor
2
Optional
Indoor
Suction
Liquid
Suction
Liquid
4AC13(B,L)18
RBCS2M18C****P - 13.00 11.50 18,100 13,000 600
3/4 3/8
3/4 3/8 3/4 3/8 0.053 A4TXV01
RBCS2M24V****P - 14.00 12.00 18,300 13,200 600
3/4 3/8
3/4 3/8 3/4 3/8 0.053 A4TXV01
4AC13(B,L)24
RBCS2M24C****T - 13.50 11.00 23,000 16,600 750
3/4 3/8
3/4 3/8 3/4 3/8 0.057 A4TXV01
RBCS2M24V****P - 14.00 11.50 23,200 16,700 750
3/4 3/8
3/4 3/8 3/4 3/8 0.057 A4TXV01
4AC13(B,L)30
RBCS2M30C****P - 13.50 11.00 28,200 21,200 1000
3/4 3/8
3/4 3/8 3/4 3/8 0.062 A4TXV01
RBCS2M36V****P - 14.00 12.00 28,600 21,500 1000
3/4 3/8
3/4 3/8 3/4 3/8 0.062 A4TXV01
4AC13(B,L)36
RBCS2M36C****T - 13.50 11.50 34,200 25,300 1200
3/4 3/8
3/4 3/8 3/4 3/8 0.065 A4TXV02
RBCS2M36V****P - 14.00 12.00 34,400 25,500 1200
3/4
3/8 3/4 3/8 3/4 3/8 0.065 A4TXV02
4AC13(B,L)42
RBCS2M42****P - 13.50 11.00 39,500 29,600 1400 7/8 3/8 7/8 3/8 7/8 3/8 0.074 A4TXV02
RBCS2M42V****P - 14.00 11.50 40,000 30,000 1400 7/8 3/8 7/8 3/8 7/8 3/8 0.074 A4TXV02
4AC13(B,L)48
RBCS2M48****P - 13.50 11.00 47,000 33,400 1550 7/8 3/8 7/8 3/8 7/8 3/8 0.082 H4TXV03
RBCS2M48V****P - 14.00 11.50 47,500 33,700 1550 7/8 3/8 7/8 3/8 7/8 3/8 0.082 H4TXV03
4AC13(B,L)60
RBCS2M60****P - 13.00 11.00 56,000 39,800 1750 7/8 3/8 7/8 3/8 1-1/8 3/8 0.090 H4TXV03
RBCS2M60V****P - 13.50 11.00 56,500 40,100 1750 7/8 3/8 7/8 3/8 1-1/8 3/8 0.090 H4TXV03
CoolingPerformancewithAirHandlersandFurnaces
1
Certified in accordance with Unitary Air Conditioner Certification Program, which is based on ARI Standard 210/240.
2
Required to achieve ARI rating.
