Ducane 4AC13 - Cooling Performance - Extended Ratings

4AC13 Split System Air Conditioner
13
Outdoor
Model
Indoor
Model
Indoor
Temp
DB/WB
˚F
Outdoor Temp - DB˚F
65 82 95 105 115
Btuh S/T kW Btuh S/T kW Btuh S/T kW Btuh S/T kW Btuh S/T kW
4AC13(B,L)18 EC1P19
85/72 22,700 .59 1.26 20,800 .63 1.48 19,300 .66 1.66 18,300 .68 1.84 17,200 .69 2.02
80/67 22,100 .63 1.25 19,100 .68 1.46 18,000 .71 1.64 16,500 .74 1.82 15,100 .77 2.00
75/63 17,700 .75 1.24 16,600 .77 1.46 15,700 .78 1.63 14,200 .83 1.81 12,700 .87 1.99
4AC13(B,L)24 EC1P23
85/72 28,500 .61 1.65 26,700 .64 1.93 25,400 .66 2.15 23,400 .69 2.39 21,400 .72 2.63
80/67 26,200 .68 1.63 25,200 .70 1.88 23,400 .72 2.13 21,200 .76 2.37 19,000 .80 2.61
75/63 24,400 .70 1.61 22,400 .73 1.89 20,900 .76 2.10 18,800 .81 2.33 16,800 .85 2.57
4AC13(B,L)30 EC1P29
85/72 32,900 .63 1.97 31,800 .65 2.31 30,900 .66 2.57 28,500 .70 2.85 26,100 .74 3.12
80/67 31,000 .70 1.94 29,700 .70 2.25 28,000 .75 2.55 25,600 .79 2.82 23,300 .82 3.09
75/63 29,400 .72 1.92 27,100 .75 2.25 25,300 .78 2.51 23,000 .82 2.77 20,700 .86 3.04
4AC13(B,L)36 EC1P36
85/72 38,000 .58 2.35 36,800 .62 2.76 35,900 .65 3.08 34,000 .69 3.43 32,200 .72 3.79
80/67 36,300 .65 2.33 35,700 .70 2.72 34,000 .74 3.09 31,500 .78 3.41 29,100 .82 3.74
75/63 33,900 .71 2.31 32,200 .74 2.72 31,000 .77 3.04 28,600 .83 3.37 26,100 .88 3.70
4AC13(B,L)42 EC1P42
85/72 49,400 .65 2.76 46,000 .66 3.24 43,300 .67 3.61 40,500 .70 4.02 37,700 .73 4.42
80/67 46,900 .72 2.71 42,200 .73 3.17 39,500 .75 3.59 36,500 .79 3.99 33,600 .82 4.38
75/63 43,700 .72 2.68 41,200 .78 3.16 39,200 .82 3.53 36,400 .83 3.94 33,500 .83 4.34
4AC13(B,L)48 EC1P48
85/72 53,800 .60 3.31 52,100 .62 3.90 50,900 .64 4.35 47,400 .66 4.79 44,600 .68 5.22
80/67 52,100 .68 3.24 49,900 .69 3.76 47,000 .71 4.27 43,600 .74 4.73 40,200 .77 5.19
75/63 49,500 .70 3.21 45,900 .73 3.80 43,200 .75 4.25 40,000 .78 4.69 36,900 .81 5.14
4AC13(B,L)60 EC1P62
85/72 65,300 .61 3.83 62,900 .63 4.56 61,100 .64 5.11 57,400 .66 5.67 53,800 .68 6.23
80/67 62,300 .67 3.79 58,600 .69 4.44 56,000 .71 5.09 52,300 .74 5.64 48,500 .77 6.19
75/63 59,400 .69 3.76 55,100 .72 4.47 51,900 .74 5.02 48,400 .77 4.57 44,900 .80 6.12
CoolingPerformance—ExtendedRatings
