Gear change pedal (fig. 24)
The gear change pedal is at rest when in the central
position N, and automatically returns to the central
position. When in this position, light N (3, fig. 4) on
istrument panel is on.
The pedal can be moved:
down = push down on the pedal to engage 1
st
gear and
to shift down. The N light will go out.
up = lift the pedal to engage the 2
nd
gear and then the 3
rd
,
4
th
, 5
th
and 6
th
gear. Each time you move the pedal you will
engage the next gear.
30
E
N
2
3
4
5
6
1
fig. 24
