Ducati 749DARK - Engine Oil and Viscosity; Checking and Topping Up Engine Oil

70
E
–10
Unigrade
Multigrade
010203040 ° C
40
20W–40 20W–50
15W–40 15W–50
10W–40
10W–30
10W
20W
20
30
Checking engine oil level (fig. 69)
Engine oil level can be checked through the sight glass
(1) provided on the clutch cover.
When checking oil level, the motorcycle should be
upright and the engine cold.
Allow a few minutes for oil to settle to a steady level
after stopping the engine.
Oil level should be between the marks near the sight
glass. Top up oil level with SHELL Advance Ultra 4, if low.
Undo the filler plug (2) and top up to correct level.
Refit the plug.
Important
Engine oil and oil filters must be changed by a
Ducati Dealer or Authorized Workshop at regular
intervals, as specified in the routine maintenance chart
(see Warranty Card).
Viscosity
SAE 10W-40
The other viscosity degrees indicated in the table can be
used if the local average temperature is within the limits
specified for that oil viscosity.
1
2
fig. 69
