First, disconnect the power cable of
the motor, located under the bottom
left chainstay of the frame. Just lightly
pull the two ends of the connection to
disconnect it.
Warning*
Once the bolts have been loosened on
the ends, unscrew them completely
to also remove the two snap washers,
located on the axle on the external
part of the frame.
Warning!
The position of the snap washers
is very important, they must be
positioned correctly when the
wheel is installed.
Warning!*
When the wheel needs to
be reinstalled, the correct
connection of the two end of the
power cable is very important.
– Rimozione ruota posteriore:
If removing also the rear wheel to
transport the Pedelec becomes
necessary, this is the necessary
information to follow to correctly
perform this operation:
Then unscrew the two bolts located
at the ends of the wheel axle using
two Allen keys of the right size
positioned on both sides of the axle, by
performing an opposing traction.
