Ducati Hypermotard - Right-hand Switch

The adjuster (2) on the lever allows a maximum
adjustment (Q) of 0.43 in (11 mm), while the standard
adjustment (the initial one) is 0.2 in (5 mm). If the
adjustment is not enough, work on the secondary
adjuster (3).
Attention
In presence of clutch slipping, due to wearing,
the adjuster (2) on the lever MUST NEVER be
loosened but tightened, as explained above.
If the slipping remains, go to a Ducati Dealer or
Authorized Service Center.
2
Q
Fig 90
3
Fig 91
148
