Refitting the battery
Important
For battery removal, ALWAYS contact a Ducati Dealer
or authorised Service Centre.
Install the battery in the battery support and secure it with
the elastic retaining strap (19).
Warning
Connect the positive lead (20) to the positive terminal
and the negative lead (21) to the negative terminal, as shown
in the photo.
Insert the screws (22) in the terminals (20) and (21), always
starting with the positive terminal (red lead).
Warning
Position the leads (20) and (21) as shown in the photo.
Tighten the screws (22) to a torque of 10 Nm ± 10%.
Apply grease around the battery terminal clamps to prevent
oxidation.
22
21
19
20
fig. 79

Ducati Monster 796 2011 Specifications

General

Displacement	803 cc
Compression Ratio	11:1
Power	87 hp (64 kW) @ 8250 rpm
Fuel System	Electronic fuel injection, 45 mm throttle body
Exhaust	Lightweight 2-1-2 system with catalytic converter and lambda probe
Transmission	6-speed
Final Drive	Chain; Front sprocket 15; Rear sprocket 39
Frame	Tubular steel Trellis frame
Front Suspension	43 mm upside-down fork
Front Wheel Travel	120 mm (4.7 in)
Rear Wheel Travel	148 mm (5.8 in)
Front Brake	2 x 320 mm discs, 4-piston radial caliper
Rear Brake	245 mm disc, 2-piston caliper
Front Tire	120/70 ZR17
Rear Tire	180/55 ZR17
Dry Weight	167 kg (368 lb)
Seat Height	800 mm (31.5 in)
Engine Type	L-Twin, Desmodromic, 2 valves per cylinder, air cooled
Bore x Stroke	88 mm x 66 mm
Torque	78 Nm @ 6250 rpm
Rear Suspension	Progressive linkage with preload and rebound adjustable monoshock
Fuel Capacity	15 L
