Ducati Streetfighter User Manual

Adjusting the position of the
gearchange pedal and rear brake
pedal
The position of the gearchange and rear brake
pedals in relation to the footrests can be adjusted to
suit the requirements of the rider.
Adjust the pedals as follows:
Gear change pedal
To correctly operate on the rod, remove the relevant
side fairing.

Have the gearchange rod adjusted at a Ducati
Dealer or authorised Service Centre.
Hold linkage (1) using the special flat (A) and loosen
nut (2).
Fit an open-end wrench to hexagonal element of
linkage (1) and rotate until  pedal in the
desired position.
Tighten nut (2) onto linkage.
A 1 2
Fig 146
186

Ducati Streetfighter Specifications

General

Displacement	1, 103 cc
Torque	123 Nm (90.4 lb-ft) @ 9, 500 rpm
Transmission	6-speed
Rear Brake	245 mm disc, Brembo caliper
Fuel Tank Capacity	16 L (4.23 US gal)
Front Brake	Dual 330 mm discs
Dry Weight	180 kg (397 lb)
Seat Height	845 mm (33.3 in)
