Dukane Projectors - Internal Parts

3
1
4
2
5
12
7
10
11
9
6 8
1. SAFETY INTERLOCK SWITCH
2. COOLING FAN
3. LAMP
4. REFLECTOR
5. MAST LOCK SCREW
6. LAMP
7. MIRROR
8. SAFETY INTERLOCK SWITCH
9. MAST LOCK SCREW
10. RETAINER CLIP
11. LAMP HOUSING COVER
2000 LUMEN MODELS
3000 & 4000
LUMEN MODELS
INTERNAL PARTS
