Dukane Projectors - Index of Functional Parts

2
A number of terms are used frequently in this instruction booklet.
The OVERHEAD PROJECTOR will be easier to operate if you become
familiar with the terms for the functional parts listed below:
1. OPEN HEAD
2. MAST
3. FOCUS KNOB
4. STAGE
5. STAGE OPENING LATCH TABS
6. BASE
7. CLOSED HEAD
8. POWER SWITCH
9. MAST MOUNT
INDEX OF FUNCTIONAL PARTS
P
R
IM
A
R
Y
L
A
M
PRE
S
E
R
V
E
5
8
6
3
2
1
4
9
7
