Dulux PaintPod - Removing and Replacing Roller Sleeve

CARING FOR YOUR PAINTPOD
REPLACING THE DIP TUBE AND DELIVERY TUBE
REMOVING AND REPLACING THE ROLLER SLEEVE
c
Remove the battery compartment
cover by pressing the battery
compartment release button on
the end of the handle assembly.
Remove the roller head from the
handle.
Carefully pull out at one end of the
‘roller head’ and remove the roller
sleeve.
Clean or replace the roller sleeve
and ret into the roller head. The
roller sleeve will only t one way
into the roller head. Make sure the
distribution plate and feeder roller
are in position.
Whilst holding the delivery tube,
gently push forward and lift the
roller head connector upwards to
remove from handle.
Insert the new roller head
connector (attached to delivery
tube) back into handle and gently
push forwards and down. It will
‘click’ when inserted correctly.
IMPORTANT: DO NOT force the
roller head connector, it will only
go in one way.
d
Place the delivery tube into its
holding position (in handle) and
replace the white handle cover. It
will ‘click’ when replaced correctly.
The replacement dip tube and
delivery tube are now ready for use.
Please dispose of the used dip
tube and delivery tube with normal
household waste.
a
Battery compartment cover
Battery compartment
release button
a
Roller sleeve
b
Roller
head
connector
