4. Drive - Regulates the amount of distortion the Dirty
Deed is putting out. Low settings give you a tight,
slightly overdriven tone. Turning it up increases the
distortion dramatically, for huge power chords and
endless, singing sustain.
5. True Bypass Footswitch - Removes the circuit from
your guitar’s signal via a hardwired connection from
the input jack to the output jack.
6. Input Jack - Plug in your guitar or other pedal
cable here.
7. Output Jack - Run a cable to the input of your amp
or to the next effect in your chain.
8. Power Jack - We designed this pedal to be
convenient. You can use any 9V to 18V regulated DC
adapter (negative polarity center terminal).
9. Easy Access Battery door (located on back panel) -
When it is not in use, save your battery life by removing
your guitar cable from the Input jack.
1
4
8
9
5
7
6
2
3
(on back panel)
