SPECIFICATIONS
Distortion Circuitry: Discrete MOSFET pair
Bypass: True bypass
Gain Control Range: CCW: 30dB +/- 1.5dB; CW: 63dB +/- 1.5dB
EQ Center Frequencies: Bass 90Hz; Treble 2.1 KHz
S/N Ratio at minimum gain and maximum level settings: 120dB
Noise referred to input, 400Hz to 20kHz: 1uV rms
THD @ 10mVrms input @ 1 KHz with 30dB of gain: 0.12%
Max Output before Saturation: 2.6Vrms
Input Impedance: 470K Ohms
Output Impedance: 2.8K Ohms
Power: 9V battery or external 9 to 18V Regulated DC Adapter (center negative)
Current Consumption: 6.5 mA Max
Dimensions: 2.61” x 4.90” x 1.45”
Weight: 0.8lb.without battery
