P/N# 1305029, Rev
Safety Symbols and Warnings 2
Ratings, Data, and Dimensions 3
Installation Procedure 4
Ventilation and Combustion Air 5
Connecting Supply and Return Piping Steam 7
Venting System Inspection and Installation 8
Oil Tank and Piping 8
Electrical Wiring 9
Thermostat Operation 9
Normal Sequence of Operation 11
Operating Instructions 11
Maintenance Procedures 14
Replacement Parts List 15
Service Checklist 20
KEEP THIS MANUAL NEAR BOILER j_
RETAIN FOR FUTURE REFERENCE
The following defined symbols are used throughout
this manual to notify the reader of potential hazards
of varying risk levels
ndicates an imminently hazardous situation'_
hich, if not avoided, WILL result in death or I
r!o,s!nj,,y: j
dicates a potentially hazardous situation I
hich, if not avoided, COULD result in death I
serious injury, j/
ndicates a potential hazardous situation I
hich, if not avoided, MAY result in minor or I
oderate injury. It may also be used to alert I
gainst unsafe practices. .t)
1 0 [08/04] • Printed in USA • Made In USA
MPORTANT: Read the following instructlons_
OMPLETELY before mstalhngll
1. Keep boiler area clear and free from com-
bustible materials, gasoline and other flam-
mable vapors and liquids.
2. DO NOT obstruct air openings to the boiler
room.
3. Modification, substitution or elimination of
factory equipped, supplied or specified com-
ponents may result in property damage, per-
sonal injury or the loss of life.
4. TO THE OWNER - Installation and service of
this boiler must be performed by a qualified
installer.
5. TO THE INSTALLER - Leave all instructions
with the boiler for future reference.
6. When this product is installed in the Com-
monwealth of Massachusetts the installation
must be performed by a Licensed Plumber or
_Licensed Gas Fitter.
J
All installations of boilers and venting should
be done only by a qualified expert and in
accordance with the appropriate Pennco
manual. Installing or venting a boiler or any
other gas appliance with improper methods
or materials may result in serious injury or
death due to fire or to asphyxiation from
poisonous gases such as carbon monoxide
which is odorless and invisible.
_.. J
0@
Tested For 15 LBS
ASME
/_,,or kllig Pressure
