DUOTONE SLICK 23 / SLICK 23 MANUAL
RIGGING THE FOIL WING
3.2. INFLATING THE FOIL WING
1. Lay the foil wing down on sand, grass or a surface free of hard or sharp objects as they could damage it.
2. Turn the Foil Wing with the leading edge into the wind. The bottom side of the foil wing is facing upwards
3. Connect the hook on your pump to the safety leash loop on your Foil Wing.
4. Slide the end of the foil boom into the rear loop on the strut of the foil wing. For wings sized 2.5 / 3.0 / 3.5
there are two loops on the strut. If you are using the boom in the original length, you must put the end of the
boom through the first loop and secure it in the rear loop. The front loop is for shorter booms. These are not
offered by DUOTONE. Make sure the end of the boom has been pushed in up to the rear strap.
5. Now slide the front end of the boom into the strap device provided. Make sure the rounded side of the front
tube is mounted, and the side with the central notch is facing up, and the raised sections on the left and
right are sticking out behind the strap.
6. Secure the front end of the boom first by taking both hook and loop fastenings from back to front and then
passing the upper fastening strips from the upper neoprene cap with integrated velcros from front to back
over the top.
