Troubleshooting
The message “MASTER SET MISS” is displayed on the LCD panel. Remove the master and remake the master by
following the procedure below.
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Open the upper cov
er.
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Remov
e the master left in the master feeder.
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Gently c
lose the upper cover.
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
When “PLATE EJECTION ERROR” is Displayed
When “MASTER SET MISS” is Displayed
MASTER SET MISS
Upper cover
Continue Page
•••
Reset the master and take away the cutted master.
For details,see page 75-77.
