Duplomatic 10 Series - 1 - SUPPLY COMPOSITION

4 M.I.6458-16-0110
1 - SUPPLY COMPOSITION
1 DM-16 Direct drive motor turret.
2 TMC-
*
Direct motor driver for remote installation into the machine electrical cabinet.
(See electrical manual E.M.TMC-
*
).
DUPLOMATIC SUPPLY
3 Installation of the Direct motor driver into the Electrical Cabinet and Electrical connections
between turret, driver, and CNC.
ATCUSTOMERCHARGE
4 Hydraulicequipmentandpowerpack.
5 Hydraulic connections.
CNC
I/O
MACHINE ELECTRICAL CABINET
DIRECT MOTOR
DRIVER TMC -
*
Fuses
HYDRAULICPOWER PACK
1
5 3
2
4
SUPPLY
