21
15. PARTS LIST (DFA50/80T/135C Models Only)
KEY NO. DESCRIPTION
PART NO.
QUANTITY
DFA50 DFA80T DFA135C
1 Fuel Tank Assmebly 2151-0046-01 2151-0047-01 2151-0048-01 1
2 Fuel Drain-Bolt - - 4329-0072-00 1
3 Fuel Gauge 2156-0047-00 2156-0049-00 2156-0051-00 1
4 Fuel Filter Assmbly 2155-0005-00 2155-0005-00 2155-0001-00 1
5 Fuel Cap 2151-0041-00 2151-0041-00 2151-0041-00 1
6 Power Cord 3980-0274-00 3980-0275-00 3980-0275-00 1
7 Button Support 3713-0048-00 - - 2
8 Display P.C.B Assembly 215A-0013-00 - - 1
9 Shell Lower 3111-0501-05 3111-0501-05 3111-0506-05 1
10 Flange Screw 4319-0015-00 4319-0015-00 4319-0015-00 4
11 Bushing-Grommet(S) 3231-0120-00 3231-0120-00 3231-0120-00 1
12 Bushing-Grommet(L) 3231-0121-00 3231-0121-00 3231-0121-00 2
13 Air-Line 3341-0035-00 3341-0035-00 3341-0036-00 1
14 Temperature Limit Assembly 2153-0022-00 2153-0013-00 2153-0013-00 1
15 Flange-Screw 4319-0015-00 4319-0015-00 4319-0015-00 1
16 Chamber Assembly 2152-0292-00 2152-0293-00 2152-0294-00 1
17 Bracket Photocell 3131-0159-00 3131-0159-00 3131-0159-00 1
18 Screw-BH1 4311-0068-00 4311-0068-00 4311-0068-00 2
19 Photocell Assembly *SP-KFA1007 *SP-KFA1007 *SP-KFA1007 1
20
21
22
Burner Head Assembly 2152-0120-00 2152-0121-00 2152-0122-00 1
20-1 Burner Head 3531-0026-00 3531-0026-00 3531-0025-00 1
20-2 Nozzle *SP-KFA1026 *SP-KFA1027 *SP-KFA1003 1
20-3 Washer-Nozzle Seal 4349-0016-00 4349-0016-00 4349-0016-00 2
20-4 Spring-Nozzle Seal 3431-0010-00 3431-0010-00 3431-0010-00 1
20-5 O-Ring 3311-0002-00 3311-0002-00 3311-0002-00 1
20-6 Nozzle Adaptor 3231-0178-00 3231-0178-00 3231-0179-00 1
20-7 Spark Plug *SP-KFA1008 *SP-KFA1008 *SP-KFA1009 1
20-8 Bolt-Flange 4329-0079-00 4329-0079-00 4329-0079-00 1
23
Flange Screw 4319-0015-00 4319-0015-00 4319-0015-00 3
Fuel Line 3341-0034-00 3341-0034-00 3341-0032-00 1
Motor and Pump Assembly 2154-0135-00 2154-0135-00 2154-0136-00 1
23-1 Motor 3970-0210-00 3970-0210-00 3970-0211-00 1
23-2 Capacitor 3820-0257-00 3820-0257-00 3820-0258-00 1
23-3 Motor Support 3121-0440-00 3121-0440-00 3121-0439-00 1
23-4 Nut-Hex 4331-0022-00 4331-0022-00 4331-0022-00 2
23-5 Holder Capacitor - - 3231-0182-00 1
23-6 Pump Body 3541-0022-00 3541-0022-00 3541-0022-00 1
23-7 Bolt-BH Special 4321-0198-00 4321-0198-00 4321-0198-00 2
NEVER LEAVE THE HEATER
UNATTENDED WHILE BURNING!
