22
15. PARTS LIST (DFA50/80T/135C Models Only)
KEY NO. DESCRIPTION
PART NO.
QUANTITY
DFA50 DFA80T DFA135C
23-8 Rotor *SP-KFA1000 *SP-KFA1000 *SP-KFA1000 1
23-9 Blade See SP-KFA1000 See SP-KFA1000 See SP-KFA1000 4
23-10 Insert See SP-KFA1000 See SP-KFA1000 See SP-KFA1000 1
23-11 End Pump Cover 3531-0027-00 3531-0027-00 3531-0027-00 1
23-12 Elbow 3231-0181-00 3231-0181-00 3231-0181-00 1
23-13 Lint Filter *SP-KFA1005 *SP-KFA1005 *SP-KFA1005 1
23-14 Bolt Flange 4329-0016-00 4329-0016-00 4329-0016-00 6
23-15 Output Filter See SP-KFA1005 See SP-KFA1005 See SP-KFA1005 1
23-16 End Filter Cover 3221-0029-00 3221-0029-00 3221-0029-00 1
23-17 Ball *SP-KFA1006 *SP-KFA1006 *SP-KFA1006 1
23-18 Spring See SP-KFA1006 See SP-KFA1006 See SP-KFA1006 1
23-19 Adjusting Screw See SP-KFA1006 See SP-KFA1006 See SP-KFA1006 1
23-20 Bolt Flange 4329-0016-00 4329-0016-00 4329-0016-00 4
23-21 Intake Filter See SP-KFA1005 See SP-KFA1005 See SP-KFA1005 1
26
Fan Assembly 2154-0009-00 2154-0009-00 2154-0004-00 1
27
Bolt Headless Hex Socket 4323-0004-00 4323-0004-00 4323-0004-00 1
28
Plug 3231-0054-00 3231-0054-00 3231-0054-00 1
29
Main P.C.B Assembly 215A-0048-00 215A-0073-00 215A-0074-00 1
30
Screw-TH2S 4312-0046-00 4312-0046-00 4312-0046-00 2
31
Ignitor 39E0-0071-00 39E0-0071-00 39E0-0071-00 1
32
Side Cover-Right 3121-0496-05 3121-0497-26 3121-0498-18 1
33
Power Switch 39A0-0191-00 39A0-0191-00 39A0-0191-00 1
34
Window Display - - 3231-0113-00 1
35
Flange Screw 4319-0015-00 4319-0015-00 4319-0015-00 4
36
Side Cover-Left 3121-0190-00 3121-0350-00 3121-0352-00 1
37
Flange Screw 4319-0015-00 4319-0015-00 4319-0015-00 4
38
Shell Upper 3111-0502-05 3111-0502-05 3111-0507-05 1
39
Clip Nut 3131-0182-00 3131-0182-00 - 2
40
Fan Guard 3221-0074-00 3221-0074-00 3221-0075-00 1
Flange Screw 4319-0015-00 4319-0015-00 4319-0015-00 8
24
25
Front Guard 3561-0066-00 3561-0066-00 - 1
NEVER LEAVE THE HEATER
UNATTENDED WHILE BURNING!
FOR TECHNICAL ASSISTANCE SEE YOUR LOCAL RETAILER OR CONTACT US AT:
PHONE: 814-643-1775 TECH.: 814-643-2299 FAX: 814-643-3443
EMAIL: techsvc@yourheater.comor visit our website at www.yourheater.com
