15. PARTS LIST (DFA180CV Model Only)
NEVER LEAVE THE HEATER
UNATTENDED WHILE BURNING!
KEY NO. DESCRIPTION
PART NO.
QUANTITY
DFA180CV
1 Fuel Tank Assmebly 2151-0049-01 1
2 Fuel Drain-Bolt 4329-0072-00 1
3 Fuel Gauge 2156-0051-00 1
4 Fuel Filter Assmbly 2155-0001-00 1
5 Fuel Cap 2151-0041-00 1
6 Power Cord 3980-0275-00 1
7 Shell Lower 3111-0508-05 1
8 Flange Screw 4319-0015-00 4
9 Bushing-Grommet(S) 3231-0120-00 1
10 Bushing-Grommet(L) 3231-0121-00 2
11 Air-Line 3341-0038-00 1
12 Temperature Limit Assembly 2153-0023-00 1
13 Flange-Screw 4319-0015-00 1
14 Chamber Assembly 2152-0295-00 1
15 Bracket Photocell 3131-0159-00 1
16 Screw-BH1 4311-0068-00 1
17 Photocell Assembly *SP-KFA1007 1
18
19
20
Burner Head Assembly 2152-0123-00 1
18-1
Burner Head 3531-0024-00 1
18-2
Nozzle *SP-KFA1004 1
18-3
Washer-Nozzle Seal 4349-0016-00 2
18-4
Spring-Nozzle Seal 3431-0010-00 1
18-5
O-Ring 3311-0002-00 1
18-6
Nozzle Adaptor 3231-0179-00 1
18-7
Spark Plug *SP-KFA1009 1
18-8
Bolt-Flange 4329-0079-00 1
21
Flange Screw 4319-0015-00 3
Fuel Line 3341-0034-00 1
Motor and Pump Assembly 2154-0142-00 1
21-1 Motor 3970-0212-00 1
21-2 Capacitor 3820-0258-00 1
21-3 Motor Support 3121-0439-00 1
21-4 Nut-Hex 4331-0022-00 2
21-5 Holder Capacitor 3231-0182-00 1
21-6 Pump Body 3541-0022-00 1
21-7 Bolt-BH Special 4321-0198-00 2
21-8 Rotor *SP-KFA1000 1
21-9 Blade See SP-KFA1000 4
