15. PARTS LIST (DFA180CV Model Only)
NEVER LEAVE THE HEATER
UNATTENDED WHILE BURNING!
KEY NO. DESCRIPTION
PART NO.
QUANTITY
DFA180CV
21-10 Insert See SP-KFA1000 1
21-11 End Pump Cover 3531-0027-00
1
21-12 Elbow 3231-0181-00
1
21-13 Lint Filter *SP-KFA1005
1
21-14 Bolt Flange 4329-0081-00
6
21-15 Output Filter See SP-KFA1005
1
21-16 End Filter Cover 3221-0076-00
1
21-17 Ball *SP-KFA1010
2
21-18 Spring See SP-KFA1010
2
21-19 Adjusting Screw See SP-KFA1010
2
21-20 Bolt Flange 4329-0016-00
4
21-21 Intake Filter See SP-KFA1005
1
24
Fan Assembly 2154-0007-00
1
25
Bolt Headless Hex Socket 4323-0004-00
1
26
Pressure Gauge 3740-0049-00
1
27
BTU Control Switch 2154-0070-00
1
28
Main P.C.B Assembly 215A-0074-00
1
29
Screw-TH2S 4312-0046-00
2
30
Ignitor 39E0-0071-00
1
31
Side Cover-Right 3121-0499-36
1
32
Power Switch 39A0-0191-00
1
33
Window Display 3231-0113-00
1
34
Flange Screw 4319-0015-00
4
35
Side Cover-Left 3121-0354-00
1
36
Flange Screw 4319-0015-00
4
37
Shell Upper 3111-0349-01
1
22
Fan Guard 3221-0075-00
1
23
Flange Screw 4319-0015-00
8
FOR TECHNICAL ASSISTANCE SEE YOUR LOCAL RETAILER OR CONTACT US AT:
PHONE: 814-643-1775 TECH.: 814-643-2299 FAX: 814-643-3443
EMAIL: techsvc@yourheater.comor visit our website at www.yourheater.com
