SECTION II
OPERATING PROCEDURES
SAFETY PRECAUTIONS
Before you start operating the hoist, familiarize yourself with the following
safety precautions.
HOIST CAPACITY
CAUTION
!
Do not exceed hoist capacities shown. Excessive loads will result in dan-
gerous operating conditions.
HOIST LIFTING CAPACITY*
HOIST
MODEL
BODY LENGTH MOUNTING
HEIGHT
CAPACITY BODY
& PAYLOAD
ft. m. in. mm
tons
U.S. Metric
1715 8 2.438 13-3/8 340 12.0 109
9 2.743 14-3/8 365 10.5 9.5
10 3.048 14-3/8 365 9.0 8.2
1721 9 2.743 14-3/8 365 13.5 12.2
10 3.048 14-3/8 365 12.0 10.9
1821 9 2.743 15-3/8 391 17.0 15.4
10 3.048 15-3/8 391 15.0 13.6
11 3.353 15-3/8 391 13.0 11.8
12 3.658 15-3/8 391 12.0 10.9
1824 HD 10 3.048 16-3/8 416 21.0 19.0
11 3.353 16-3/8 416 19.0 17.2
12 3658 16-3/8 416 17.0 15A
13 3.962 16-3/8 416 15.0 13.6
14 4267 16-3/8 416 14.0 12.7
(Cont)
