20-25mm from center leading edge.
Elevator
6-10mm
6-10mm
6-12mm
6-12mm
20-25mm~
10-15mm
10-15mm
Rudder
Aileron
*Elevator ‘low rates’ 6mm ‘high rates’ 10mm in either direction from neutral.
*Rudder ‘low rates’ 6mm ‘high rates’ 12mm in either direction from neutral.
*Aileron ‘low rates’ 10mm ‘high rates’ 15mm in either direction from neutral.
2. The Excalibur handles exceptionally in flight and that’s not down to good design alone, but a good
pre-flight set-up too. Before you fly your Excalibur please follow the recommended settings below
for optimum handling and performance.
The recommended center of gravity (CG) for the Excalibur is approximately 20-25mm from the
leading wing when measured along the plastic of the wing fairing. Your Excalibur should balance
within the range using anything from a 1800mah - 2200mah 40-65C 4S lipo installed directly under
the canopy hatch.
3.
8
