Durafly EXCALIBUR - Contents of Box; Required to Complete Model; Optional Parts

1. Main wing panels
2. Fuselage
3. V-tail stabilizer
REQUIRED TO COMPLETE MODEL:
OrangeRx T-SIX 2.4GHz 6CH
Programmable Tx:
Part No. 9403000001 Mode 1
9403000002 Mode 2
OrangeRX R620X
6Ch 2.4Ghz:
Part No. 9171000757-0
Turnigy Graphene 1800mah
65C 4S Lipo:
Part No. 9067000133-0
A-SPEC G2 2200mah
65C 4S Lipo:
Part No. 9472000004-0
1
2
3
4
7
5
6
In its ‘Plug n Fly’ format the Excalibur will still require some additional electronic components to get
it ‘flight ready’. Durafly recommends the products below for optimum performance and great value.
Available at hobbyking.com. If you are viewing this manual online, click
7. Upper tail plate
8. Slope nose cone
9. Wing spars
4. Control & mounting accessories
5. Prop and spinner assembly
6. Fuselage patch kit plates
8
10. Canopy/hatch
9
10
OPTIONAL PARTS:
To further extend the Excalibur's performance and versatility, the below optional parts are available
directly from Hobbyking.com The ‘Pro prop’ upgrade is for those more experienced pilots that are
looking to squeeze the maximum performance out of the stock set-up and can be purchased
directly from the site. The ‘FPV canopy hatch’ is a free to download 3D file of the canopy from the
files tab of the listing for those that with to 3D print their own canopy and FPV the Excalibur.
2
CONTENT:
