Durafly Spitfire Mk1a - Model Setup and Calibration; Centering Control Surfaces; Checking Control Direction

Roll left
Roll right
Pitch up
Pitch down
Yaw left
Yaw right
Aileron
(Roll)
Elevator
(Pitch)
Rudder
(Yaw)
Ailerons
Elevator
Rudder
SETTING UP YOUR MODEL:
1. With your receiver installed and all servos plugged into their corresponding channels, connect
the flight battery to the ESC to power up the electronics. With the model now armed, ensure all
servos are centered and all control surfaces are level. If not, adjust by turning the control clevis’s by
hand accordingly until the control surfaces are level as shown.
Note: For safety reasons, it is advised that this is done with the prop removed from the
model.
2. Check all control surfaces are moving in the correct direction with the applicable
stick input (see below)
7
Durafly 1100mm Supermarine Spitfire Mk1a
