A
V
GUN OUTPUT FLUX WIREGASLESS GAS SOLID WIRE
6
EXTENSION CORDS
Do not use an extension cord on this Welder.
REPLACEMENT CORDS
Use only the supplied power cord for this Welder
or an identical replacement cord.
Do not install a thinner or longer cord on this
Welder.
Do not patch cords of any length together for this
item. Patches may allow moisture to penetrate the
insulation, resulting in electric shock.
CONTROLS
FRONT PANEL CONTROLS
Alarm Indicator
Work Indicator
Wire Speed/
Amperage for TIG
and MMA Knob
MIG Gun
Polarity Jumper
Negative Terminal
Positive Terminal
Cold Wire Feed
Button
Mode Switch
Voltage/
Arcforce
Knob
