Duratech DTMP140 - Specifications; Welding Settings

Power input
Phase
Frequency
Duty cycle
OCV
Max input current
Max output current
MIG (GMAW&FCAW)
120Vac
1~p
50-60Hz
20%@90A
80V
21.6A
140A
MMA (SMAW)
120Vac
1~p
50-60Hz
20%@80A
80V
23.4A
80A
TIG (GTAW)
120Vac
1~p
50-60Hz
20%@110A
14V
22.3A
110A
SPECIFICATIONS
7
WELDING SETTINGS
Refer to the Settings Chart on the inside of the Welder door for MIG Weld settings.
The chart is only intended to show general guidelines for different wire/electrode sizes and for different
thicknesses of material. The initial settings used at the beginning of a weld may need to be adjusted after
stopping and carefully inspecting the weld. Proper welding takes experience.
CONTROLS
INTERIOR CONTROLS
Wire Spool
(Not included)
Wire Inlet Liner
Wire Feed
Mechanism
Idler Arm
Feed Tensioner
Feed Roller
Knob
