7
• “ERROR” is displayed - A loose connection - check
connection of the iron to the station.
• Tip will not reach set temperature - Defective heating element
• Solder will not wet the tip - Tip temperature is too high.
Tip is badly oxidized and requires cleaning.
TROUBLESHOOTING
SPECIFICATIONS
Input Voltage 220-240V~50Hz
Power Consumption - Desoldering 80W
Power Consumption - Soldering 60W
Output Voltage 24V AC
Temperature Range 160-480°C
Vacuum Pressure 60mm HG
Weight 5.67kg
