GENERAL SPECIFICATION
Max. voltage between terminals and
earth ground
CAT II 600V
Fuse Protection F 200mA / 250V
Power 9V battery, NEDA 1604 or 6F22
Display LCD, 1999 counts, updates 2-3 seconds
Measuring Method Dual-slope integration A/D converter
Overrange Indication Only gure “1” on the display
Polarity Indication “-” displayed for negative polarity
Operating Environment 0°C to 40°C
Storage Temperature -10°C to 50°C
Low battery indication “ ” appears on the display
Size 138mm x 69mm x 31mm
Weight Approx 170g
Accuracy is specied for a period of one year after calibration and at 18 to 28°C (64°F
to 82°F) with relative humidity to 80%.
DC VOLTAGE
Range Resolution Accuracy
200mV 100µV ± 0.5% of rdg ± 2 digits
2V 1mV ± 0.5% of rdg ± 2 digits
20V 10mV ± 0.5% of rdg ± 2 digits
200V 100mV ± 0.5% of rdg ± 2 digits
600V 1V ± 0.8% of rdg ± 2 digits
Overload protection: 250V rms. For 200mV range and 600V dc or rms, ac for other
ranges.
DC CURRENT
Range Resolution Accuracy
200µA 0.1µA ± 1% of rdg ± 2 digits
2mA 1µA ± 1% of rdg ± 2 digits
20mA 10µA ± 1% of rdg ± 2 digits
200mA 100µA ± 1.5% of rdg ± 2 digits
10A 10mA ± 3% of rdg ± 2 digits
Overload protection: F 200mA/250V fuse (10A range unfused).
