AC VOLTAGE
Range Resolution Accuracy
200V 100mV ± 1.2% of rdg ± 10 digits
600V 1V ± 1.2% of rdg ± 10 digits
Overload protection: 600V DC or RMS. AC for all ranges.
Frequency range: 40Hz to 400Hz.
Response: average responding, calibrated in rms of a sine wave.
DIODE & CONTINUITY
Range Description
If continuity exists (about less than 1.5kΩ), the built-in buzzer will sound.
Shows the approximate forward voltage drop of the diode.
RESISTANCE
Overload protection: 250V DC or RMS, AC.
Range Resolution Accuracy
200Ω 0.1Ω ± 0.8% of rdg ± 3 digits
2kΩ 1Ω ± 0.8% of rdg ± 2 digits
20kΩ 10Ω ± 0.8% of rdg ± 2 digits
200kΩ 100Ω ± 0.8% of rdg ± 2 digits
2MΩ 1kΩ ± 1.0% of rdg ± 2 digits
Maximum open circuit voltage: 3.2V
Overload protection: 250V DC or RMS, AC for all ranges.
TRANSISTOR hFE TEST (0-1000)
Range Test Range Test Current Test Voltage
NPN & PNP 0-1000 lb = 10µA Vce = 3V
OPERATION - DC VOLTAGE MEASUREMENT
• Connect the red test lead to the “VΩmA” jack and the black lead to the “COM”
jack.
• Set the rotary switch at the desired DCV position. If the voltage to be measured is
not known beforehand, set the range switch at the highest range position and then
reduce it until a satisfactory resolution is obtained.
• Connect the test leads across the source or load being measured.
• Read the voltage value on the LCD display along with the polarity of the red lead
connection.
