When using optional pinion gears, adjust the motor position
by using the insert that matches the pinion size.
16T 22T
12 3
3
4
14T 19T 24T 17T 23T 15T 18T 21T20T
2.6x8mm S/T Screw
..........1
8
9
2.6x6mm Screw
..........2
3mm Set Screw
20T Pinion
4.5mm
..........1
