Duratrax Vendetta - Page 17

17
The pivot ball threads
should cover half of
the hole.
The end of the screw
should be even with
the inside edge.
24 25
3x8mm Set Screw
The end of the screw
should be even with
the inside edge.
The pivot ball threads
should cover half of
the hole.
..........1
3x8mm Set Screw
..........1
RIGHT LEFT
26 27
RIGHT
LEFT
