Duratrax Vendetta - Page 20

20
33
34
Insert body clips into the 3rd and 14th
holes of the body posts. Adjust the post
height for different bodies.
1
3
14
3x8mm Set Screw
..........1
RIGHT
35
3x8mm Set Screw
..........1
LEFT
The end of the screw
should be even with
the inside edge.
The end of the screw
should be even with
the inside edge.
