Duratrax Vendetta - Page 25

25
46
48
47
Oil
Completely fill
the shock body
with shock oil.
Slowly move the
shaft up and down
to remove bubbles.
Slowly tighten
the shock cap
onto the shock
body to allow
any remaining
air to escape.
x4
x4
2x5mm Washer
..........2
2mm Lock Nut
..........2
2x16mm Cap Screw
..........2
2x12mm Screw
2x16mm
2x12mm
..........2
