Note the direction of the rear
reverser lock (145).
Grease the
thrust bearing.
Use a generous amount
of thread lock.
The recessed side of the 2-speed
clutch (119) goes on last. Tighten
the set screw (J) through the slot
in the 2
nd
gear housing (120).
Be sure not to overtighten or
tighten the shift point adjustment
set screw (G).
!
USE THREADLOCK
ON ALL SET SCREWS.
TRANSMISSION
