32
Item Part Qty Description Item Part Qty Description
106 1 Gasoline engine
149
DF6500H-31073-A 2 Handle Head
107
DF6500H-33013-A 4 Flange bolt
150
DF6500H-31074-A 4 Gasket, handle
108
DF3800H-33005-A 1 Generator Stay
151 DF6500H-31058-F
1 Hand push F
109
DF6500H-33003-A 1 Bolt
152 DF6500H-31058-A
1 Hand push A
110
GB/T97.1-1987 1 Plain washer Ф 10
153
GBT16674-B8-45 2 Bolt, handle M8×45
111
GB/T2776-1994 1 Bearing 6204DU
154
GBT6183-N-8 10 Nut M 8
112
DF8000H-33110-B 1 Rotor Assembly
155
GB6183-N-10 4 Flange nut M10
113
DF8000H-33104-A-23 1 Stator & Rotor Assy.
156
GBT5789-86 4 Flange bolt M8 x 16
114
DF3800H-33023 1 Generator Fan
157
DF2500H- 31019-B 2 Ф 3.2 Pin
115
DF6500H-33016 1 Stator cover
158
DF6500H-31017-O 2 Wheels 10”
116
DF6500H-33120-B
1
Stator Assy.
159
XP8500E-31020-A 2 Foot
117
DF3800H-33001-A 1 Brush Assembly
160
XP8500E-31018-A 1 Well shaft
118
DF6500H-33011-A 1 Voltage Regulator
161 DFD2500H-31061-A 1 battery plate
119
DF3800H-33002-A 1 Connecting Plate
162
31038-004 1 Positive wire of battery
120
GBT5789-B5-12 9 Screw M5×12
163
31040-004 1 Negative Wire of battery
121 DF3800H-33006 1
Generator end cover
164
31300-002 1 9Ah battery
122
DF3800H-14322-D 1 Stripe, fuel tank
165
34107 1 Earth Terminal Set
123
DF3800H-14300-B 1 Fuel tank
166
GBT5789-B6-16 4 Bolt M6×16
124
14307 1 Fuel Filler
167
34204-003 1 Receptacle (30A)
125
14310 1 Packing ring
168
34204-005 2 Receptacle (20A)
126
14306 1 Fuel filler cap comp
169
34206-046 1
Circuit protector
127
14303 1 Fuel sensor
170
GBT801-B3-8 Bolt M3x 8
128
GB 819-95 2 Screw M5 x 10
171
34208-004 1 8A Circuit Protector
129
14313 1 Gasket Fuel Sensor
172
34204-038 1
DC poles A
130
GB/T5787-1996 4 Flange bolt M6 x 25
173
34204-039 1
DC poles B
131
DF2500H-14311-A 4 Washer
174
34205-001 1 Voltmeter
132
14305 4 Collar
175
34211 1 Diode assay
133
14304 4 Cushion
176
34244 1 Engine switch
134
DJ188FD-14007-A 1 Outlet Pipe
177
34109 1 Boot, switch wire
135
DJ168F-14008-A 1 Tube Cock
178
34109-B 1 Boot, main wire harness
136
DJ168F-14008-A 1 Tube Cock
179
34109-A 1 Boot, AC output wire
137
DF2500H-14302-A 1 Fuel Cock
180
34212-A 1 Wire harness Assy.
138
DF3800H-14403-A 1 Outer Hood
181
34101-A 1 Control Panel
139
GB5787-1996 2 Flange bolt M8 X 25
182
34208-028 1 Fuse
140
DJ188FD-14010-B 1 Gasket Exhaust Pipe
183
34102-A 1 Control panel case
141
DF6500H-14400-D 1 Muffer Assembly
184
34217-001 1 Current sensor
142
DF3800H-14416-B
1 Inner Hood
185
DFD6500H-34213-001 1 Wire
143
DF3800H-14403-A 1 Side Hood
186
34225 1 Charger
144
GBT5789-B6-16 12 Bolt M6 x 16
187
34226-001 1 lamp
145
XP6500E-31100-A 1 Frame comp
188
34203-005 1 Idle control switch
146
DF3800H-31201-A 2 Bottom rubber A
189
34202-001 1 Voltage selector
147
DF3800H-31202-A 2 Bottom rubber B
148
GB6183-N-8 4 Flange nut M8
