Step 5:
A
G
1pc
6pcs
Ensure that the holes on the
left and right are aligned.
16
Step 6:
G
A
E
F
H
E
6pcs
F
6pcs
9
8
17
17
17
Page 8
With an assistant, carefully lift both the Headboard & Footboard at the same time, do
not let
the bed frame twist. Lift and turn the bed frame on its side holding the bed upright for safety.
Attach the Fabric Base (16) to bottom of the Side Rails, Headboard & Footboard with the
velcro tape. Ensure the fabric is fixed evenly all round.
Fabric Base Attachment
Constructing the Ottoman Metal Frame
Rear Ottoman Metal Frame
Ensure the pre-drilled
holes are facing upwards
Front Ottoman Metal Frame
Side Ottoman Metal Frame
Centre Ottoman Metal Frame
Side Ottoman Metal Frame
H
1pc
To Next Page
