10.
11.
8pcs
P-10/30
1
Dx8
M6*35mm Bolt
D
D
1
12
4pcs
E F
Ø7.8*30mm Dowel
Ø15mm Cam lock
4pcs
Fx4
Ex4
E
F
Attach Parts to the Top.
Attach the Top to the Frame.
