M6*35mm Bolt
6pcs
D
Dx6
22
22
E
Ø15mm Cam lock
6pcs
Ex6
D
E
E
28.
27.
P-23/30
27
Attach the Bolts to the Drawer Front.
Assemble the Drawer.
