1-PHASE ELECTRICAL SCHEMATIC
To be connected to:
120V/ 60HZ / 1-Phase - 15 Amp Supply
IF PROTECTED BY FUSES, USE TIME DELAY TYPE
CIRCUIT MUST BE PROTECTED
To be connected to:
240V/ 60HZ / 1-Phase - 10 Amp Supply
IF PROTECTED BY FUSES, USE TIME DELAY TYPE
CIRCUIT MUST BE PROTECTED
32
SWITCH
P4-921-0129
HEATER
P4-921-0127
SWITCH
P4-921-0129
HEATER
P4-921-0128
