Duux Edge - Product Description and Main Parts; 3.1. Main Parts

5
EN
3. Product description
The Edge heater is a heater that allows the user to control the surrounding room temperature.
This product has dierent functions and temperature ranges which provide the user with multiple
possibilities suited for their needs.
The control panel allows the user to adjust any function at any time. The product can be placed on the
oor, but can also be mounted to the wall to t any interior.
3.1. Main parts
2
7
3
1
98 q w e r t y u i
4
56
1
Duux Edge Heater
2
Control panel
3
Ventilation slots
4
Mounting slots
5
Rubber protection plugs
6
Mounting holes
7
Power rocker switch
8
Power cord
9
Power plug
q
Set of oor stands (2×)
w
Vertical mounting bracket
e
Horizontal mounting bracket
r
M5 × 10 mm bolt – Philips
heads (4×)
t
4.2 × 30 mm screw – Philips
head (4×)
y
3.8 × 8mm screw – Philips
head (1×)
u
6 × 28 mm plug (4×)
i
Remote control
