79 3/4"
45"
15 1/8"
49 7/16"
73 3/16"
1 7/8"
CSC300
CONTROLLER WITH
VARIABLE SPEED DRIVE
EMERGENCY
STOP
LIFTING POINTS
PRESSURE
GAUGE &
SAFETY
VALVE
VSD AIR
INLET
FILTER
REMOVABLE
SERVICE
DOOR
9/16" X 1"
SLOT
AIR OUTLET
3/4" NPT
BALL VALVE
MOUNTED
AIR DRYER WITH
2M (6FT) CORD,
SEPARATE 115V
POWER SUPPLY
REQUIRED
8 11/16"
7 11/16"
10 5/16"
16 5/16"
17 7/8"
REMOVABLE
TOP PANEL
POWER IN
1" CONDUIT
OPENING
DUCTIBLE EXHAUST AIR
OUTLET WITH 1/4"
MOUNTING INSERTS
26 1/2"
23 3/4"
VSD AIR
OUTLET
REMOVABLE
SIDE PANEL
11 5/8"
7 7/8"
15 1/4"
14 1/4"
AIR INTAKE OPENING WITH
1/4" MOUNINTING INSERTS
REMOVABLE
REAR PANEL
COALESCING
FILTER WITH
6MM DRAIN
TUBE
1/4" MANUAL DRAIN
REMOVABLE
SIDE PANEL
*MOTOR AMP IS 100% OF FULL LOAD,
@70% & 40% THE AMP WILL DECREASE
PROPORTIONALLY
INSTALLATION REQUIREMENTS
1. MAINTAIN 3 FEET DISTANCE
FROM WALLS AND OTHER
OBJECTS FOR PURPOSE OF
COOLING AND SERVICING
2. COMPRESSOR MUST BE LEVEL
AND ANCHORED DOWN TO
SOLID LEVEL FLOOR.
3. AMBIENT CONDITIONS:
10ºC (50ºF) MIN. 40ºC (104ºF) MAX.
4. APPROACH TEMP. FROM TANK 5ºC (41ºF).
MODEL
NO.
HP
PRESSURE
PSI
SCFM @ 120, 145 PSI
NOMINAL
SOUND @
1 METRE
MOTOR NAMEPLATE VOLTAGE*
AIR
RECEIVER
GAL.
DRYER
FILTER
ELEMENT
WEIGHT
LBS
3-PHASE
100% CAP.
70% CAP. 40% CAP.
200V 230V 460V 575V
G25TDVSD 25
110-120
100
70
40
68 dBA
65 56 28
22.7
120
ASD-100
115V, 60Hz,
11.6A
1
MICRON
1758
135-145
96
67
38
G30TDVSD 30
110-120
116
81
46
69 dBA
78 68 34 27 120
ASD-100
115V, 60Hz,
11.6A
1
MICRON
1758
135-145
112
78
45
FUSE TABLE
VOLTAGE
PHASE
FUSE TYPE
FUSE AMP
25 HP 30 HP
200
3
J FAST-
ACTING
(DFJ/HSJ)
80 110
230 70 80
460 35 40
575 35 35
IMPORTANT NOTE: This print is the confidential property of DV SYTEMS, INC. It is not to be used
or reproduced in any manner, nor submitted to other parties for examination without the prior
approval of DV SYSTEMS, INC. DV SYSTEMS, INC. is continually trying to improve its products,
specifications subject to change without notice.
DESCRIPTION OF DRAWING
DRAWING NO.
SHT NO
REV.
NAME OF PROJECT
DRAWN BY
CHECKED BY
DATE
SCALE
G25-30TDVSD SCREW COMPRESSOR
WITH DRYER
LT
1/05/17
N.T.S
SALES-ENGINEERING DRAWING
G25TDVSD
G30TDVSD
