DVO DIAMOND - Fork Cleaning and Seal Installation; Cleaning Inner Surfaces and Foam Rings

.
// pg. 14
Pour 25cc’s of 7.5 wt. oil into the air
side.
Tip: Pull up on the casting to make
room for the oil to pour in.
Use the 18mm socket to tighten both
footnuts to 10nm.
Pull the casting down until the bottom
of the cartridges are touching the oor
of the casting.
Use the 32mm socket to tighten both
top caps to 20nm.
Insert both adjusters. Reinstall the two detents into the
detent insert.
Tip: You can apply some grease to the
detents to keep them from falling out.
40.37.
41.38.
42.39.
// pg. 13
