// pg. 12// pg. 11
Reinsert upper assembly into
casting. Start with the stanchion tubes
at a slight angle as shown.
Raise the upper assembly until the
crown touches the top caps of the
cartridges.
Hand tighten top caps into crown.
Once the stanchion tube has passed
the dust seal, insert straight down.
Flip the fork upside down and it should
look like this.
Now insert both cartridges. Insert 35cc’s of 7.5 wt. oil into the
damper side.
Tip: Pull up on the casting to make
room for the oil to pour in.
34.31.
35.32.
36.33.
