DVTel CF-4221-00 Fixed IP Camera User & Installation Guide
5
Definition
Remarks
Network LEDs
Network connection and activity indication
I/O
1
Output＋
5
GND
2
Output－
6
D－ (Future use)
3
Input＋
7
D＋(Future use)
4
Input－
VIDEO (BNC connector)
For video output
Micro SD Card slot
For video and snapshots storage (card not included)
AC 24V/DC 12V
connector
(AC 24V Model)
＋
AC 24V: Power-1
DC 12V: Power
LINE
OUT
LINE IN
MIC IN
NETWORK
AUTO
IRIS
PoE
1 2 3 4
I/O
DC
VIDEO
AC 24V
DC 12V
AC 24V: Earth GND
DC 12V: Reserved
－
AC 24V: Power-2
DC 12V: GND
3 System Requirements
To access the IP Camera via a web browser, please ensure your PC has the proper network
connection, and meets system requirements as described below.
Items
System Requirement
Personal Computer
1. Intel® Pentium® M, 2.16 GHz or Intel® Core
TM
2 Duo, 2.0 GHz
2. 2 GB RAM or more
Operating System
Windows VISTA, Windows XP, Windows 7
Web Browser
Microsoft Internet Explorer 6.0 or later
Firefox
Chrome
Safari
Network Card
10Base-T (10 Mbps) or 100Base-TX (100 Mbps) operation
Viewer
ActiveX control plug-in for Microsoft IE
