Dymax EC-Series Flood Lamps for UVCS Conveyors User Guide
Spare Parts and Accessories
Replacement/Spare Parts
Item
Part Number
Fuses
Fuse, F 6.25 Amp
35141
Personal Protection Equipment
Protective Goggles — Clear
35612
Protective Goggles — Gray (standard model included with unit)
35285
Lamps
Lamp, Metal Halide 400 Watt UV (Standard)
38560
Lamp, Mercury Vapor 400 Watt UV (Optional)
36970
Lamp, Visible 400 Watt (Optional)
36658
Lamp Base Replacement Kits
35979
Miscellaneous
Temperature Control Kit (5000 UVCS and 5000 UVCS SideCure)
38693
Power Switch
36288
Specifications
Specifications
Table 2. Flood Lamp Specifications
Property
Specification
Models
2000-EC
for use with UVCS Conveyors
5000-EC
for use with SideCure Conveyors
5000-EC
for use with UVCS Conveyors
Typical Initial Output Intensity
at UV-A* (320-395 nm)
75 mW/cm
2
225 mW/cm
2
Weight
3.4 lbs. [1.5 kg]
2.7 lbs. [1.2 kg]
Dimensions, W x D x H
10.5" x 9.0" x 7.5"
[26.7 x 22.9 x 19.1 cm]
6.75" x 6.75" x 8.0"
[17.2 x 17.2 x 20.3 cm]
6.75" x 6.75" x 7.0"
[17.2 x 17.2 x 17.8 cm]
* 2000-EC: Nominal intensity 2.1" below the Reflector; 5000-EC: Intensity 3" below bottom edge of Lamp/Reflector Assembly Housing. All measured with an
ACCU-CAL™ 50 UV Radiometer calibrated and traceable to NIST.
