Dymo LabelManager 420P User Manual

8
Printing Labels with DYMO Label™ v.8 Software
The following figure shows some of the major features available in DYMO Label v.8.
To print your first label
1 Click in the built-in software to start DYMO Label v.8 software.
The first time you start DYMO Label software, a list of available label types is
displayed on the left side of the window and a blank label is displayed in the
Edit area.
2 From the Labels tab, select a tape label and then select a layout.
Make sure that the width of the tape label you select matches the width of
the label cassette loaded in the label maker.
3 Click once on the tape label in the Edit area and type some text.
4 Click to print the label.
For complete details on using the software, refer to the online Help.
Insert text,
addresses,
images,
shapes, lines,
barcodes,
dates, and
counters.
Apply a layout to
a label.
Store your
favorite
addresses or
other data in the
Address Book;
automatically
insert the data
on your label.
Visually
choose your
label type and
apply layouts.
Select a label
maker to print
your labels.
Print a label.
Capture an area of the screen
and insert on your label.

Dymo LabelManager 420P Specifications

General

Color	No
Print technology	Thermal transfer
Vertical printing	Yes
Maximum resolution	180 x 180 DPI
Maximum print height	14.9 mm
Maximum printing width	- mm
Display	LCD
Product color	Black
Keyboard layout	ABC
Display number of lines	4 lines
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Windows operating systems supported	Windows 7, Windows 8, Windows Vista
Tape type	D1
Tape cutting	Manual
Number of styles	10
Built-in barcodes	Code 128 (A/B/C), EAN13, EAN8, UPC-A, UPC-E
Number of box types	8
Label memory	15 label(s)
Number of batteries supported	1
Maximum label width	19 mm
Supported paper width	6, 9, 12, 19 mm
Package depth	390 mm
Package width	265 mm
Package height	320 mm
Package weight	6500 g
Cables included	USB
Pallet width	800 mm
Pallet height	1110 mm
Pallet length	1200 mm
Pallet weight	181100 g
Harmonized System (HS) code	84433210
Number of cartons per pallet	144 pc(s)

Weight and Dimensions

Depth	57 mm
Width	215 mm
Height	104 mm
Weight	415 g
