Dymo LetraTag LT-100T User Manual

18
Caring for Your Labelmaker
Your labelmaker is designed to give you long and trouble-free
service, while requiring very little maintenance. Clean your
labelmaker from time to time to keep it working properly. Clean the
cutter blade each time you replace the label cassette.
To clean the cutter blade
Press in and hold
1. Dampen a cotton ball with alcohol.
2. Remove the label cassette.
3. Place the tip of a ball-point pen or
pencil on the black post as shown in
Figure 6, and press the post down.
Print head
Figure 6
4. While holding down the post, press and
hold the cutter lever to expose the cutter blade.
5. Release the post and clean both sides of the blade with the
cotton ball.
6. Release the cutter lever.
Ç You can also follow this procedure if the cutter blade becomes
lodged in the forward position and will not move.
LT Momentum AUS.indd 18 19-03-2007 09:13:42

Dymo LetraTag LT-100T Specifications

General

Display	LCD
Product color	Gray
Keyboard layout	QWERTY
Battery type	AA
Auto power off	Yes
Number of batteries supported	4
Number of styles	7
Number of box types	8
Number of characters	195
Number of printing lines (max)	2
Label memory	9 label(s)
Country of origin	China
Package depth	643 mm
Package width	260 mm
Package height	280 mm
Package weight	3800 g
Batteries included	No
Print technology	Direct thermal
Maximum resolution	180 x 180 DPI
Maximum label width	12 mm
Pallet width	800 mm
Pallet height	990 mm
Pallet length	1200 mm
Pallet weight	83100 g
Number of cartons per pallet	90 pc(s)

Weight and Dimensions

Depth	80 mm
Width	220 mm
Height	229 mm
Weight	400 g
