Dyna-Glo DGF350CSP - Grill Body and Side Table Assembly

11
ASSEMBLY INSTRUCTIONS
9. Assemble the temp gauge (B) onto the hood.
Please use the washer and wing nut pre-
assembled with temp gauge to install the temp
gauge (B) onto the hood.
9
10. Assemble the grill body assembly (C) onto the
cart assembly with four M6x16 bolts (II).
Please note this step needs two people to
uplift the grill body assembly.
10
II
B
Hardware Used
II
M6x16 Bolt
x 4
C
